Continuous Casting Machine 200Kg Capacity for Gold, Silver, Copper

Continuous Casting Machine 200Kg Capacity for Gold, Silver, Copper

Location:Pawtucket, RI

or
Call 1-800-619-GOLD

Description

Additional Details:


Panel Board:

Will be equipped with all necessary switches and controls for efficient operation. The panel will be wired and instruments will be tested before leaving our plant.


Cooling System:

Cooling system specially designed pressure less cooling chamber including prevision flow meter control to monitor accurately the cooling and water temperature gauges with micro-processor control to activate the alarm system. Water pressure control is also interfaced with the alarm system.


Withdrawal System:

The withdrawal mechanism is designed with mechanical and hydraulic interface. The motor drive is controlled electronically with processor pulse.


Crucible:

Manufacture from high purity. Graphite is machined to precision tolerance.


Dies:

Casting Dies are precision manufactured from high density graphite.

Show All

Specifications

ManufacturerFerrara
Model200KG
Year2026
ConditionNew
Stock Number779538
Crucible Size200Kg
Maximum Casting Capacity9" wide(228mm) 3.75" Diam(100mm)
Output Capacity180Kg per hour
Voltage208 / 220 / 240, 50-60 CY
Kw Power94.8
Amp Power264
Maximum Operating Temperature1350 C (246o F)
Furance BoxHeavy duty HR steel construction with removable top.
Heating ElementThe heating element is constructed of silicone carbide. The element is designed to provide trouble free life. The element has a unique design the easiest and shortest way to replace. (normal replacement time is 15 min. with Furnace HOT)
InsulationThe furnace chamber contains multiple courses of high quality refractory and thermal efficiency.
Atmosphere ControlInternally the Furnace operates under atmosphere inert gas. This will minimize oxidation of graphite crucible and die.
Heat ZoneMulti Zone heating system for better heat curve accuracy.
TemperatureMicroprocessor temperature control with time proportion and cycle rate calibrated for Type K thermocouple 0 to 2,300o F for close line control. (includes HI-Limit safety)
Overall Dimensions40' ft x 8' ft x 7'
