200-Ton Automated Hydraulic Coining Press

200-Ton Automated Hydraulic Coining Press

Location:Ex-Factory

or
Call 1-800-619-GOLD

Description

With automatic pneumatic protective baffle

With die ejection device

With PLC touch screen

With fully automated feeding transfer system

Show All

Specifications

Model200S
Year2025
ConditionNew
Stock Number779487
Tonnage200 Tons
VoltageTo order specs
Motor Power22Kw
Nominal Pressure of Master Cylinder200 Ton
Max System Pressure25MPa
Max Storke of Working Platform2000mm
Opening Height400mm
Height of working platform from ground900mm
Upward speed of movable work table220mm/s
Return speed of movable work table165mm/s
Work Progress8mm/s
Movable work table size550mm x 750mm
Overall Size1510mm x 1765mm x 2620mm
Estimated weight2400Kg
